型 号 |
最小加工径 |
|
|
|
|
|
|
刀片 |
螺丝 |
扳手 |
出水孔 |
|
Specification |
Min dia |
d |
F |
L1 |
L |
H |
a |
Insert |
Screw |
Wrench |
Water hole |
|
S16N-SVUBR/L11 |
22 |
16 |
12.5 |
27 |
160 |
15 |
10° |
VB..1103.. |
M2.5*7 |
Q08 |
- |
|
S20Q-SVUBR/L11 |
27 |
20 |
14 |
34 |
180 |
18 |
8° |
VB..1103.. |
M2.5*7 |
Q08 |
- |
|
H16N-SVUBR/L11 |
22 |
16 |
11.5 |
27 |
160
|
15 |
10° |
VB..1103.. |
M2.5*7 |
Q08 |
- |
|
S16N-SVUCR/L11 |
22 |
16 |
11.5 |
27 |
160 |
15 |
10° |
VC..1103.. |
M2.5*7 |
Q08 |
- |
|
S20Q-SVUCR/L11 |
27 |
20 |
14 |
34 |
180
|
18 |
8° |
VC..1103.. |
M2.5*7 |
Q08 |
- |
|
H16N-SVUCR/L11 |
22 |
16 |
11.5 |
27 |
160 |
15 |
10° |
VC..1103.. |
M2.5*7 |
Q08 |
- |
|
S20Q-SVUBR/L16 |
31 |
20 |
19 |
34 |
180
|
18 |
8° |
VB..1604.. |
M3.5*9 |
Q15 |
- |
|
S25R-SVUBR/L16 |
35 |
25 |
20 |
43 |
200 |
23 |
6° |
VB..1604.. |
M3.5*9 |
Q15 |
- |
|
S32S-SVUBR/L16 |
42 |
32 |
22.5 |
54 |
250
|
30 |
8° |
VB..1604.. |
M3.5*9 |
Q15 |
- |
|
S40T-SVUBR/L16 |
51 |
40 |
27 |
68 |
300 |
37 |
8° |
VB..1604.. |
M3.5*9 |
Q15 |
- |
|
S20Q-SVUCR/L16 |
31 |
20 |
19 |
34 |
180
|
18 |
8° |
VC..1604.. |
M3.5*9 |
Q15 |
- |
|
S25R-SVUCR/L16 |
35 |
25 |
20 |
43 |
200 |
23 |
6° |
VC..1604.. |
M3.5*9 |
Q15 |
- |
|
S32S-SVUCR/L16 |
42 |
32 |
22.5 |
54 |
250
|
30 |
8° |
VC..1604.. |
M3.5*9 |
Q15 |
- |
|
S40T-SVUCR/L16 |
51 |
40 |
27 |
68 |
300 |
37 |
6° |
VC..1604.. |
M3.5*9 |
Q15 |
- |
|
A16N-SVUBR/L11 |
22 |
16 |
11.5 |
27 |
160
|
15 |
10° |
VB..1103.. |
M2.5*7 |
Q08 |
√ |
|
A20Q-SVUBR/L11 |
27 |
20 |
14 |
34 |
180 |
18 |
8° |
VB..1103.. |
M2.5*7 |
Q08 |
√ |
|
A16N-SVUCR/L11 |
22 |
16 |
11.5 |
27 |
160
|
15 |
10° |
VC..1103.. |
M2.5*7 |
Q08 |
√ |
|
A20Q-SVUCR/L11 |
27 |
20 |
14 |
34 |
180 |
18 |
8° |
VC..1103.. |
M2.5*7 |
Q08 |
√ |
|
A20Q-SVUBR/L16 |
31 |
20 |
19 |
34 |
180
|
18 |
8° |
VB..1604.. |
M3.5*9 |
Q15 |
√ |
| 适用 Suitable:德克刀片 DEREK Insert |
|
|
