型 号 |
最小加工径 |
|
|
|
|
|
|
刀片 |
螺丝 |
扳手 |
出水孔 |
|
Specification |
Min dia |
d |
F |
L1 |
L |
H |
a |
Insert |
Screw |
Wrench |
Water hole |
|
S10K-STFPR/L08 |
13 |
10 |
6 |
17 |
125 |
9 |
8° |
TP..0802.. |
M2*5 |
Q06 |
- |
|
S08K-STFPR/L09 |
11 |
8 |
5 |
15 |
125 |
7 |
10° |
TP..0902.. |
M2.5*5 |
Q08 |
- |
|
S10K-STFPR/L09 |
13 |
10 |
6 |
17 |
125
|
9 |
8° |
TP..0902.. |
M2.5*6 |
Q08 |
- |
|
S10K-STFPR/L11 |
13 |
10 |
6 |
17 |
125 |
9 |
12° |
TP..1103.. |
M3*6 |
Q08 |
- |
|
S12M-STFPR/L11 |
16 |
12 |
7 |
20 |
150
|
11 |
10° |
TP..1103.. |
M3*6 |
Q08 |
- |
|
S16N-STFPR/L11 |
20 |
16 |
9 |
27 |
160 |
15 |
8° |
TP..1103.. |
M3*7 |
Q08 |
- |
|
S20Q-STFPR/L11 |
24 |
20 |
11 |
34 |
180
|
18 |
6° |
TP..1103.. |
M3*7 |
Q08 |
- |
|
S20Q-STFPR/L16 |
24 |
20 |
11.5 |
34 |
180 |
18 |
6° |
TP..1603.. |
M3.5*9 |
Q15 |
- |
|
S25R-STFPR/L16 |
31 |
25 |
14 |
43 |
200
|
23 |
4° |
TP..1603.. |
M3.5*9 |
Q15 |
- |
|
C08K-STFPR/L09 |
11 |
8 |
5 |
15 |
125 |
7 |
10° |
TP..0902.. |
M2.5*5 |
Q08 |
- |
|
C10M-STFPR/L09 |
13 |
10 |
6 |
17 |
150
|
9 |
8° |
TP..0902.. |
M2.5*6 |
Q08 |
- |
|
C10M-STFPR/L11 |
13 |
10 |
6 |
17 |
150 |
9 |
12° |
TP..1103.. |
M3*6 |
Q08 |
- |
|
C12Q-STFPR/L11 |
16 |
12 |
7 |
20 |
180
|
11 |
10° |
TP..1103.. |
M3*6 |
Q08 |
- |
|
C16R-STFPR/L11 |
20 |
16 |
9 |
27 |
200 |
15 |
8° |
TP..1103.. |
M3*7 |
Q08 |
- |
|
C20S-STFPR/L11 |
24 |
20 |
11 |
34 |
250
|
19 |
6° |
TP..1103.. |
M3*7 |
Q08 |
- |
|
H08K-STFPR/L09 |
11 |
8 |
5 |
15 |
125 |
7 |
10° |
TP..0902.. |
M2.5*5 |
Q08 |
- |
|
H10K-STFPR/L09 |
13 |
10 |
6 |
17 |
125
|
9 |
8° |
TP..0902.. |
M2.5*6 |
Q08 |
- |
|
H10K-STFPR/L11 |
13 |
10 |
6 |
17 |
125 |
9 |
12° |
TP..1103.. |
M3*6 |
Q08 |
- |
|
H12M-STFPR/L11 |
16 |
12 |
7 |
20 |
150
|
11 |
10° |
TP..1103.. |
M3*6 |
Q08 |
- |
|
H16N-STFPR/L11 |
20 |
16 |
9 |
27 |
160 |
15 |
8° |
TP..1103.. |
M3*7 |
Q08 |
- |
|
A10K-STFPR/L08 |
13 |
10 |
6 |
17 |
125
|
9 |
8° |
TP..0802.. |
M2*5 |
Q06 |
√ |
|
A08K-STFPR/L09 |
11 |
8 |
5 |
15 |
125 |
7 |
10° |
TP..0902.. |
M2.5*6 |
Q08 |
√ |
|
A10K-STFPR/L09 |
13 |
10 |
6 |
17 |
125
|
9 |
8° |
TP..0902.. |
M2.5*6 |
Q08 |
√ |
|
A12M-STFPR/L11 |
16 |
12 |
7 |
20 |
150 |
11 |
10° |
TP..1103.. |
M3*6 |
Q08 |
√ |
|
A16N-STFPR/L11 |
20 |
16 |
9 |
27 |
160
|
15 |
8° |
TP..1103.. |
M3*7 |
Q08 |
√ |
|
A20Q-STFPR/L16 |
24 |
20 |
11.5 |
34 |
180 |
18 |
6° |
TP..1603.. |
M3.5*9 |
Q15 |
√ |
|
A25R-STFPR/L16 |
31 |
25 |
14 |
43 |
200
|
23 |
4° |
TP..1603.. |
M3.5*9 |
Q15 |
√ |
| 适用 Suitable:德克刀片 DEREK Insert |
|
|
